Telehender MAGNi TH 5.5-19

18.8m

5.500kg

Ne

14,10m

Download

The TH 5.5-19 is a fixed telescopic handler particularly suited for demanding locations in light industry. Powered by a 55 kW Deutz engine, it can safely reach a height of 18.80 meters on rough terrain, thanks to its four-wheel drive and automatic leveling system, which operates on both the wheels and stabilizers. The hydrostatic transmission provides precision and maneuverability. This machine is compatible with a wide range of attachments and features an R.F.I.D system that enables automatic recognition of attachments and creation of relative load charts. The model also includes a tire leveling system that allows the operator to adjust the machine’s tilt, ensuring that the entire load chart is available for any type of operation, even when terrain tilt could otherwise affect lifting performance.

Additional features:

• Lowered design for increased stability
• Available with Deutz Stage V / Stage IV Final / Stage IIIA engines
• Standard rotating stabilizers for optimized lifting capacity up to 5.5 tons
• 350 bar L / S hydraulic system
