Telehender MAGNi TH 4.5-19

18.8m

4.500kg

Ne

10,40m

The TH 4.5-19 is a fixed telescopic handler particularly suited for demanding locations in light industry. Powered by a 55 kW Deutz engine, it can safely reach a height of 18.80 meters on rough terrain, thanks to its four-wheel drive and automatic leveling system, which operates on both wheels and stabilizers. The hydrostatic transmission offers precision and maneuverability. This machine is compatible with a wide range of attachments and is equipped with an R.F.I.D system that allows for automatic recognition of attachments and the creation of relative load charts. The model features a tire leveling system that enables the operator to adjust the machine’s tilt, ensuring that the entire load chart is available for any type of operation, even when terrain tilt might otherwise affect lifting performance.

Additional features:

  • Lowered design for increased stability
  • Available with Deutz Stage V / Stage IV Final / Stage IIIA engines
  • Standard rotating stabilizers for optimized lifting capacity up to 5.5 tons
  • 350 bar L / S hydraulic system

Gallery

Related products

TH 4.5-19

TH 5.5-19

TH 5.5-24

Standard equipment

24-month Warranty

Cup holde

34°-58° -negotiable incline

360° Rotation

Stage V-Engine

Designed cabin

Automatic adjustment
