Telehender MAGNI TH 3-6

5.8m

3.500kg

Ne

3,2m

Download

With a capacity of 3 tons (6613 lbs) and a lifting height of 5.8 meters (19 ft), the new TH 3.6 combines compact dimensions with impressive performance. In fact, it is the most compact fixed telescopic handler in the TH range, designed for the construction and logistics sectors. It can lift a maximum load to a height of 5.4 meters (17.7 ft), 2,500 kg (5511 lbs) to maximum height, and 1,100 kg (2425 lbs) at a horizontal reach of over 3 meters (10 ft). Its low-profile design makes it ideal for tight spaces while maintaining optimal ground clearance for rough terrain.

These features, along with a 55 kW (75 hp) Deutz Stage V engine, enable a maximum speed of 35 km/h (21 mph). Four-wheel drive and hydrostatic transmission provide exceptional stability and maneuverability with three steering modes: front, concentric, and crab steering.
